Why metal scrap should be briquette before remelting?

metal scrap recycle



1, Can squeeze out over 90% cooling oil, reduce black smoking when remelting.

2, Block density >= 5200 Kg/CBM, save storage space and improve melter efficiency.



Metal chips briquete press introduction:

Metal Chips Briquetting Press

big Metal Chip Briquetter

Metal scrap briquetting press machine can compact the different kinds of chips like cast iron,aluminum,copper,magnesium,titanium,molybdenum etc metal scrap chips into high density blocks without any additive.
it is fully hydraulic control equipment, by PLC control, the whole working process automatically, reduce labor cost.

Metal scrap no need any addtive, can be compacted to be blocks directly.

We also can supply automatic feeding, discharging device to build automation metal scrap briquetting press line.

Anyang metal chips briquette machine design advantages:

  • Hydraulic system adopts two-way cartridge valve, with the good sealing performance, good open and close characteristics, pollution resistant etc advantages.
  • Special unloading loop and the liquid electrical switch protection circuit is arranged in the hydraulic system, to make the machine run smoothly, but also improve the service life of hydraulic components.
  • The electric control adopts the manual,automatic and two times feeding technology, can conveniently adjust the operation mode and the feeding length, in order to get the material pressing block suppression of different materials and sizes.
  • The machine adopts the micro movement hopper on pressing device,solved the not easy to feed and discharge problem,also reduce the abrasion of the guard of discharging.
  • The hydraulic cylinder adopts the main pressure cylinder and fast forward cylinder connected to form the composite cylinder, improve the operating speed, reducing the energy consumption of the motor, but also improve the production efficiency.
  • The machine adopts PLC control
  • The machine pressed metal block has large diameter, high density, not easily broken, good surface finish, not easy oxidation etc advantages.
  • This machine adopts a fully enclosed structure form, can recycling cutting fluid in the metal chips and prevent oil leaking pollution.

Metal scrap briquetter applicability:

Metal scrap briquetting press machine can compact many kinds of metal chips such as: cast iron,aluminum,copper,magnesium,titanium,molybdenum etc metal crap chips into high density blocks .

Metal briquetter technical parameters:

Item

Unit

Y83A-160

Y83-160

Y83-230

Y83-300

Y83-800

Y83-1000

Nominal force

KN

1600

1600

2300

3000

8000

10000

Block size

Mm

Φ90×

(60-85)

Φ90×

(60-110)

Φ110×

(70-120)

Φ120×

(70-120)

Φ180×

(165-180)

Φ220×

(200-250)

Block density

Kg/m3

≥5200-5400

≥5200-5400

≥5200-5400

≥5200-5400

≥5200-5400

≥5200-5400

Oil pressure

Mpa

23

16

23

21

25

25

Out put

T/h

0.6-0.9

0.6-0.9

1.0-1.5

1.2-1.8

6-7.5

8.5-12

Total power

Kw

24.2

24.2

39.2

47.2

185

225

Weight

Kg

4500

6000

7500

8800

50000

60000

Outside size

Mm

4900×1470

×1522

4100×1086

×2006

4100×1086

×2006

5000×1600

×2600

8000×6500

×2500

9000×7500

×2500

Metal Chip Briquetter Working Videos

Y83-1000 metal chip briquetter compress casting iron chip to be block

7 sets of metal briqutte press build automatic metal blocks compacting line in Mexico.

briquette press compact copper scrap to be blocks



Block quality test
